Cable excellence engineered through quality

Audio, Broadcast and Lighting

Event Series Audio & Broadcast Cables for the professional user with no compromise on performance or durability.

Belcom's range of Audio & Broadcast Cables have been developed over two decades using "state of the art" materials and expertise. Coupled with our range of installation cables we have stock to meet most industry applications, with a commitment to provide innovation and adaptation of cables to meet new requirements.

Audio

Event® Series audio cables are available as single pair, single quad, or as multicore versions.

The standard product has a technical polymer (TPM) as the sheathing material which is soft and pliable but also robust. The single pair and multicore/pair versions are also available with FireFighter Low Smoke Zero Halogen (LSZH) sheath for use in fixed installations in public buildings.

Event® Series starquad cables are available with TPM sheath, LSZH sheath and Polyurethane (PUR) sheath on the single quad and LSZH or PUR versions on the multiquad.

Speaker

Event® VHP Series standard speaker cables are produced for mobile or temporary hire applications using a technical polymer (TPM) which is soft and pliable but also very robust.

Event® ZHP Series is intended for use in fixed installations in public buildings, stadia, or marine applications this series is manufactured using FireFighter LSZH materials.

Event®500series is designed to deliver a good level of performance in most multiroom and home cinema applications this version also uses FireFighter LSZH materials but is colour coded pink to help its identification when installed with other cables on tray or behind plaster.

Microphone and Instrument

Event® microphone “MLX” and instrument “ICEX” cables are manufactured using an enlarged sheath made from a technical polymer (TPM) with spiral “LAP” screen. The microphone cable is available as a balanced mic. in several colours or a starquad mic., both cables have a Kevlar threads to increase their strength. The overall result is a kink resistant very durable but soft and pliable product which can be used time and time again for multiple events.

Event® Instrument cable has a special semi conductive layer and spiral “LAP” screen, the double shielding helps to provide immunity from noise. ICEX is also kink resistant very durable.

Digital Lighting Cables DMX

DMX512 is an RS485 based communications protocol that is most used to control stage lighting and effects. DMX512 stands for digital multiplex 512.This means that 512 channels are controlled digitally through one data cable. A channel is a set of 255 steps that are assigned to control attributes in each light. This may be a colour like red, green, or blue, and intensity, strobe, pan/tilt, or other attributes.

Event® DMX cables are available in flame retardant PVC or TPM sheath for patching or portable applications, PUR harsh environment double screened for portable/trailing applications or FireFighter Low Smoke Zero Halogen (LSZH) for fixed installations in public buildings.

Hybrid versions with power and data or scroller applications are also available from stock.

Broadcast

Event® broadcast cables include a range of Ultra High Definition coax cables which provide high performance 4K ready signal transmission, engineered to exceed the SMPTE Return Loss (RL) requirements for UHDTV and optimising transmission distance. These cables have FireFighter LSZH sheath as standard. Event®Series 12GHz connectors and tooling are also available from stock.

Camera cables using traditional Triax designs in soft flexible material for studio as well as PUR and LSZH versions. Belcom also have Hybrid fibre & power cables according to SMPTE 311M-HD

Tactical Ethernet

The requirement for high quality Ethernet cables in Audio & Broadcast is as important as any other industry but it is particularly important that any designs make allowances for the demands of this harsh environment.

The challenge to create compliant cables which are durable and portable has been met within the Event®Series and is available from CAT5e to CAT 7.

Lighting Power and Control

Event®Series Lighting power and control include cables for stage lighting in soft pliable materials, Low Smoke Zero Halogen, Harmonised rubber or heat resistant silicone.
